Russia Connector 2PM-14 Series 4Pin Male Panel Socket – 2РМТ14Б4Ш1В1В

Ask Lasest Price
Brand Name :	RAYMO
Model Number :	2РМТ14КПН4Г1В1В
Certification :	CE/ROHS/REACH/SGS/ISO9001
Supply Ability :	50000PCS/month
Delivery Time :	5-7 working days

Add to Cart

Product Details
Company Profile

Russia Connector 2PM-14 Series 4Pin Male Panel Socket – 2РМТ14Б4Ш1В1В

Russian ОНЦ-БС, РБМ4, СНЦ23, СНЦ127,2РМТ, 2РМДТ , 2РТТ connectors are coming !!!

All types of Circular Connector from OEM Manufacturer in China

Russia Connector 2PM-14 Series 4Pin Male Panel Socket – 2РМТ14Б4Ш1В1В

Prct Description 2PM 2PX CONNECTORS:

PM,2PMД Small circular electrical connector, used for circuit connections in electrical and radio devices. The plug and receptacle are connected through threaded connection nuts.

2РМГ,2РМДГ.2РМГП,2РМГПД are Sealed through wall type. Localized models:2PX (The 2РМ.2РМД model of the series is called 2PX, and the combination code is unified)

2PM series connector mainly adopts the technology of Russian connector, which is widely used in electrical connection and signal transmission between equipment, and its unique shape and structure design can make up some defects in use of many other similar connectors, such as the unique design of the shell threading hole and the tail screw, make it more convenient and scientific to use. The structural design of the internal insulator and pin socket also enhances its unique stability and reliability. This series of connectors also has a certain waterproof performance, which can prevent outdoor rain and other phenomena.

With years of experience in prction Russian 2PM Connector, Raymo can supply a wide range of Russian 2PM Connector. High quality Russian 2PM Connector can meet many applications.
if you need, please contact with us about Russian 2PM Connector. In addition to the prct list below, you can also customize your own unique Russian Connector according to your specific needs

2PM/2PX series connector technical performance :

Technical Parameters 2PM,2PMД 2PX 2RMD CONNECTORS
Sereis	2PM,2PMД series connectors
Material	Die-cast Aluminum, Surface Oxidation Treatment
Shell Size	2PM14/2PM18/2PM22/2PM24 /2PM27/2PM30/2PM33/2PM36/2PM42/2PM45
Contacts No	4/7/8/10/19/20/22/24/32/45/50 Pin
Ambient temperature	- 60°C~100°C - 60°C~200°C (Seal)
Terminals	Solder
Impact	1000g(once);100g(multiple times);
Contact diameter	Φ1.0mm
Mechanical Life	Insert and unplug 500 times
Connection methods	Thread connection
Technical conditions	ГЕО.364.126ТУ

Model Description 2PM,2PMД 2RMD 2PX CONNECTORS

Description	Chinese PN	Russian PN
Series Name	unsealed( 2PX )	unsealed(2PM,2PMД ), unsealed heat-resistant(2PMT,2PMДT ), sealed(2PMГ,2PMГД ),Sealed through walls(2PMГП,2PMГПД )
Series Name	seal( 2PX-M, Sealing through walls( 2PX-C )
Shell standard size (mm)	14,18,22,24,27,30,33,36,39,42,45	14,18,22,24,27,30,33,36,39,42,45
Contact type	J( male) K( female ),	Ш(male) Г(female)
Total number of contacts	4,7,8,10,19,20,22,24,30,32,42,45,50	4,7,8,10,19,20,22,24,30,32,42,45,50
Connector Type	unmarked-plug,A-unsealed receptacle,M( C )-sealed receptacle( wall through receptacle )	Б(fixed side), К(free side )
Tail attachment	P-straight shielding,Q-straight unshielded,R-angular shielded,S-angular unshielded	П-straight,У-angular,Э-shielded,Н-unshielded
Contact Group	1-Φ1,2-Φ1+Φ1.5,3-Φ2+Φ3,4-Φ1+Φ3,5-Φ1.5,6-Φ1.5+Φ3,7-Φ1.5+Φ2+Φ3,8-Φ1.5+Φ2,9-Φ3	1-Φ1,2-Φ1+Φ1.5,3-Φ2+Φ3,4-Φ1+Φ3,5-Φ1.5,6-Φ1.5+Φ3,7-Φ1.5+Φ2+Φ3,8-Φ1.5+Φ2,9-Φ3
Contact plating	B( gold), unmarked( silver), Note: M/sealed, nickel plated, C/through wall, nickel plated	A( gold ), B( silver ), E( nickel )
Left Plug	U

Russia Connector 2PM-14 Series 4Pin Male Panel Socket – 2РМТ14Б4Ш1В1В

2PX 2PM connector Application

Company Information 2PM CONNECTORS

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED as a professional in design and manufacture all kinds of connectors and special cables, have accumulated rich experience in development and prction for kinds of cables and its related connector adapter.With RED/Teradek Bond/ARRI Camera Cable, Canon / Sony Camera Power Cable, SDI Cable, USB Cable, Video Cable, CCD Cable... We supply different OEM/ODM services serve as different application and requirement.
Our prcts are widely used in kinds of harsh environment and applications, like industrial control devices, medical equipment, measuring and inspecting equipment, audio & visual equipment etc. Furthermore, it has excellent compatibility with many leading supplier.
We always adhere to the spirit of innovation, continue to intrce new prcts series include M5,M8,M9,M12,M16,M23 and other data connectors.With IP68, ISO9001,Rohs,CE, REACH certificate approved. СОЕДИНИТЕЛИ ОНЦ-БС-1(2) СНЦ127,СНЦ-23 2РМТ, 2РМДТ PC
Russia Connector 2PM-14 Series 4Pin Male Panel Socket – 2РМТ14Б4Ш1В1В

2PM Connectors certificate:

All connectors can be customized according customer requets!

2PM CONNECTORS Support and Services:

Technical Support and Service for Circular Push Pull Connectors

We provide comprehensive techical support and service for our Circular Push Pull Connectors. Our team is highly experienced in providing technical solutions for various applications.
Our team is available to assist customers with installation, troubleshooting, and repairs. We also offer on-site assistance and training to ensure that customers are able to use the prct to its fullest potential.
We are dedicated to providing excellent customer service and our team is available 24/7 to answer any questions or provide technical support.
We also offer a wide range of after-sales services, such as warranty extensions and prct upgrades.
If you have any questions or require any assistance, please do not hesitate to contact us.

Q1. Can I have a sample ?Yes, Samples are available for quality testing.

Q2. What about the prction lead time?
We have stock, fast delivery below 5,000 pieces.

Q3. How do you ship the goods and how long does it take to arrive?
We often ship by DHL, UPS, FedEx,TNT,SF or EMS. It usually takes 3-5 days to arrive.

Q4. Is it OEM available?
Yes. We have rich experience and good ability to put your design and idea into real prct, normally it take about 20 to 30 days for new prct from mold design to final prction.
